It is possible to set the user name list instead of that proposed by default.Īfter clicking OK button the named list will be saved in the folder:Ĭ:\Users\User_name\AppData\Roaming|Nanosoft AS\ nanoCAD 23.0 \PlotConfigs\ To sort through the sheets in alphabetical order, click on the header of the Layout column.Ĭreates the publish list only from the current document.ĭeletes all layouts from the dialog list to create a new publish list.Ĭlick this button to open the Save publish list as dialog box: Please note that when sorting the list by file name, layout names are displayed not in ascending or descending order, but in the order in which they are located in their files. To sort alphabetically by a specific column (parameter), click on the column heading. Left double click on the column names separator automatically changes the columns width. If the sheet has no assigned plotter, the value None is displayed.Ĭolumn to display size and orientation of the selected paper. This set will be assigned to all selected layouts.Ĭolumn to display the name of plotter assigned to the sheet. To do this, select several layouts, and in one of them specify the desired set of layout options. Using multiple selection ( Ctrl and Shift keys), you can assign a page setup to multiple pages at once. You can import layout presets from drawing files (*.dwg), drawing template files (*.dwt), graphics interchange format files (*.dxf), CAD standards files (*.dws). In the drop-down list, you can select any other set of parameters present in the document and available for this layout, or import it from an external file. If the sheet does not have an assigned page setup, the value None is displayed. For the model space the Model value is displayed.Ĭolumn to display the named page setup assigned to the sheet. Left double click on the column switches the status from Plot to Not plot.Ĭolumn to display the name of the layout tab in layout space.

- The plot is forbidden (in case of incorrect plot settings, for example, plotter is not assigned).

When changing the plotter, a new file is created.įor example, if in the dialog box Plotter 1 is assigned to first sheets, Plotter 2 to several next sheets, and Plotter 1 for the rest, then 3 files will be created – two separate files for Plotter 1 and one file for Plotter 2. When assigning different plotters for different sheets, the plot is carried out to separate files for each plotter. If the same plotter is assigned to all sheets, all sheets will be placed in one file. The sheets plot is carried out in the order specified in the dialog box. Turns on/off the mode to plot sheets to the file, for example, when plotting on a virtual printer. Specifies the number of copies to publish.

Current – List of all layouts available in the opened documents.

At that the paper size closest to that specified in the page setup is selected automatically.ĪTTENTION! When selecting a single plot device for all sheets in the list, the paper size specified in the device settings is ignored.ĭrop-down list containing the named publish lists available to plot.īy default (if there are no publish lists saved by the user) two lists are displayed: The selected P lotter assigned in page setups position ensures plotting with use of plot devices assigned in the page setups for each drawing.įor batch plot of all data on a particular device, it should be selected in the list.

Selects a plot device to output the plot result (plotter, printer, PDF-printer, etc.).

The order of the sheets in the *.pdf-file corresponds to the order of the sheets in the list.Īfter starting the command, the Publish dialog box opens: The Multi-sheet job option allows you to place sheet list in one or more files, for example, when creating *.pdf-files using virtual printers. The formed sheets list (plot set) can be stored for further use. Having preliminary selected several sheets using Ctrl and Shift keys, you can delete entire groups of sheets, move them up and down the list, set sheet parameters for them. There is a possibility to sort sheets in the list, add and delete sheets from the list.

The simultaneous plot of sheets from model space and from layout space is also possible.įor each sheet in a dialog it is possible to specify the page setups, including that different printers can be assigned to different sheets. The command allows you to create and send to print the list of drawing sheets from one or several files both from model space and from layout space.
